Description
Indigo S-Class Motorised Projector Lift
The Indigo S-Class Motorised Projector Lift is quiet and reliable. The lift retracts your projector to ceiling level and above. Once retracted the projector lift sits flush with the ceiling, blending in seamlessly. This is the perfect solution for your home cinema or even more so, the lounge, where the projector can be easily hidden when not in use.
Projector Lifts hide your projector away in the ceiling giving you a sleek finish.
Creating an in ceiling projector is easy with our specialised manufactured motorised projector mounts. Designed and engineered to the highest standards. These electric projector lifts are ceiling mounted and when recessed create a sleek finish.
These electric projector lifts feature a unique lightweight construction which encases the projector whilst retaining a smooth exterior profile. Designed with installation in mind they can easily be fitted to standard ceilings creating the most compact in-ceiling projector lifts available.
*BEFORE YOU ORDER A LIFT PLEASE CONTACT US TO DISCUSS YOUR REQUIREMENTS. SOME OF OUR LIFTS IF NOT IN STOCK HAVE A 2-3 WEEK LEAD TIME.
View S-Class Installation Details >>
Lift Selection
When selecting a lift, ensure there are adequate internal dimensions for the projector – allowing enough for ventilation, installation tolerances and cable management.
It is important to also understand some projector lifts will not suit a retrofit and may require good ceiling access for setting of lifts’ tolerances. Some lifts also feature better options that can be utilised to match a ceiling’s painted surface.
Particular constraints may limit your available options. For support in choosing the right option for your room and projector please contact one of our team.
Features
- The projector lift will lower to a set distance will the touch of a button
- Utilise an optional infrared and RF remote or with the built in switch control
- Wiring is made tidy, simple and out of the way using the built in wire clips.
- The lift adopts a 3-scissor design to stabilise the projector and a powerful, quiet, belt drive system.
- Full instructions are included
Concealed Solution
A unique lightweight construction encases the projector whilst retaining a smooth exterior profile. This enables home owners to have a fully recessed ceiling lift mechanism that is only seen when it’s meant to be.
Easy Installation
As with our screens, lifts are designed with installation in mind, and can easily be fitted to standard ceilings creating the most compact in-ceiling projector lifts available.
Built In Control System
Designed and programmed in-house, our control system provides the most advanced features of any screen in the world.
Quiet and Precise
Our linear actuator drive motor providse the fastest, most reliable, and precise operation. Linked to our own advanced current sensing control system ensures that the ceiling lift closes seamlessly every time with near silent operation of only 35dB.
Specifications
S180
- AxBxC (mm): 700x508x220
- Lift Height H (mm): 1800
- Lift Height C (mm): 220
- Max’m Load (kg) 50
- Travelling Distance (mm) 1580
- Net Weight (kg): 25
- Packing Dimensions LxWxH (mm): 780x640x380
S240
- AxBxC (mm): 700x508x240
- Lift Height H (mm): 2400
- Lift Height C (mm): 240
- Max’m Load (kg) 50
- Travelling Distance (mm) 2160
- Net Weight (kg): 26
- Packing Dimensions LxWxH (mm): 780x640x380
S300
- AxBxC (mm): 700x508x280
- Lift Height H (mm): 3000
- Lift Height C (mm): 280
- Max’m Load (kg) 50
- Travelling Distance (mm) 2720
- Net Weight (kg): 29.5
- Packing Dimensions LxWxH (mm): 780x640x380
S360
- AxBxC (mm): 700x508x320
- Lift Height H (mm): 3600
- Lift Height C (mm): 320
- Max’m Load (kg) 50
- Travelling Distance (mm) 3280
- Net Weight (kg): 30
- Packing Dimensions LxWxH (mm): 780x640x410
