QED Performance Graphite RCA Interconnect

$89.00 inc GST


The QED Performance Graphite RCA Interconnect utilises design concepts from the high end Reference range

These concepts will optimise audio performance when connecting your CD player, DAC or Tuner to your amplifier or receiver.

Do you need an expert?

Our customers tell us that they count on our team for more than just knowledge: they’re always friendly & ready to help with all their questions. Contact our team CJ, Bensan or Toki on 092744515 or via [email protected]



SKU: QE610 Categories: , , , Brand:

Description

The multi-award winning QED Performance Graphite RCA Interconnect presents the Performance Audio analogue interconnect.

Performance Audio utilises design concepts from the high end Reference range to optimise audio performance when connecting your CD player, DAC or Tuner to your amplifier or receiver. These include quasi-balanced geometry, low capacitance dielectric materials and 24k gold plated RCA plugs. All QED cables are covered by a lifetime guarantee.



  • 99.999% Oxygen Free Copper conductors – Provide a low resistance pathway for the audio signal
  • Low density polyethylene dielectric – because of its low dielectric constant this material has been used to cut down on the amount of audio signal energy lost due to cable capacitance
  • Ergonomically sculptured zinc plated alloy barrel – Provides ease of installation and a stunning finish



Quasi-balanced geometry
Signal and return conductors are twisted together in the QED Performance Graphite RCA Interconnect to give a level of common mode noise rejection above that of conventional unbalanced cable.



Electrostatic Screen
Provides immunity from external high voltage noise signals. Only connected at the source equipment end hence the directionality arrows on the cable jacket.



24k gold plated phono plugs
Because gold does not tarnish it provides a lasting low resistance contact when using the QED Performance Graphite RCA Interconnect.



Award 1Award 2Award 2



Specifications

  • 99.999% Oxygen Free Copper (OFC) conductors with LDPE dielectric Quasi-balanced twisted pair geometry
  • Al/Mylar wrap provides 100% electrostatic shield structure
  • OFC drain wire completes electrostatic screening
  • 24k Gold plated QED 6 leaf RCA plugs
  • Capacitance: 115 pF/m
  • Inductance: 0.74 μH/m
  • Loop resistance: 0.160 Ω/m
  • Dissipation Factor: 0.0012
  • QED Lifetime Guarantee

Additional information

Weight 0.4 kg
Dimensions 20 × 20 × 15 cm
Brand

QED
