Marantz Model 10 2ch Reference Integrated Amplifier

Description

Marantz Model 10 2ch Reference Integrated Amplifier

The Marantz Model 10 2ch Reference Integrated Amplifier is the best of the best!

From the triple-layer aluminum chassis with copper shielding to entirely original multi-layer PCBs, isolated sub-enclosures, and all new HDAM modules.

MODEL 10 is the product of decades of expertise in audio engineering, setting a new benchmark with meticulous construction, state-of-the art technologies, and elegant design.

Features

• 2 Channels
• 250 Watts per Channel
• All-New Marantz SMPS
• Fully balanced dual mono amplifiers
• Phono MM/MC
• Copper-plated chassis

Inspired by our past, engineered for our future

MODEL 10 is their new reference in amplifier design and the most powerful and finest sounding integrated amplifier Marantz has ever made.

Sound Master Tuned

MODEL10 retains the sonic Marantz signatures of warmth, spaciousness, and resolution.

However, advances in design and precise tuning by the Sound Master result in the purest expression of the Marantz sound ever. As a result, the listener experiences more detail, lower distortion, and higher dynamic range than ever before.

Iconic Details Reimagined for Tomorrow

Designed with a brushed aluminum front, MODEL 10 is encased in a copper-plated, triple-layered chassis with illuminated mesh cover grille.

Lighting inside the amplifier showcases the circuit boards, high-quality components, and specially designed transformer case.

In a nod to the Marantz design DNA, MODEL10’s porthole houses a HD TFT Color Display for volume and input selection, along with a digital level meter that behaves like vintage analog meters.

Crafted in Shirakawa, Japan

MODEL 10 was conceived and engineered in our facilities in Shirakawa, Japan to deliver the highest performance.

Perfect Pairs

• LINK 10n – LINK 10n is a highly versatile and fully featured high-end streaming preamplifier. Its advanced functionality makes it the ideal choice for those looking for a flexible, high-performance component for their reference audio system.
• SACD 10 – Featuring a proprietary SACDM-3 disc transport, Marantz Musical Filtering, and next-generation HDAM circuitry, SACD 10 offers high-resolution audio support for external source components and includes additional digital input provision for other sources.

Specifications

General

• Unit (W × H × D mm): 440 × 192 × 473
• Cabinet Size: 440 × 192 × 422
• Net weight: 33.7kg
• Packaging Dimensions (W × H × D mm): 600 × 379 × 540
• Packaging gross weight: 39.0kg
• Carton Color: 1 Color (Material color: Brown Printing: Black)
• Panel Color: Black / Marantz Champagne
• Front (Center) Panel: Anodized machined aluminium
• Back-shell: Anodized machined aluminium
• Front panel illumination: Yes (All sides, Dimmer)
• Side cover: Aluminium (Thickness: Max 15.8mm)
• Top cover: Aluminium (Thickness: 6mm)
• Top cover (Center) ventilation hole material: Stainless mesh
• Interior illumination: Yes, dimmable
• Rear Panel: Copper Plated
• Chassis Material: Copper Plated
• Bottom Layer / Bottom plate: Triple layer Copper plated
• Front panel illumination: Yes (All sides, Dimmer)
• Volume Knob: Solid aluminium (Bearing construction)
• Input Selector: Solid aluminium (Bearing construction)
• Foot: Solid Aluminium Copper plated (H: 18.5mm)
• Heatsink for Power Amplifier: Extruded Aluminium

Audio

• Rated Output Power
  • 250W + 250W (8ohm,20Hz-20kHz,THD 0.05 %)
  • 500W + 500W (4ohm,20Hz-20kHz,THD 0.05 %)
• Speaker Impedance: 4~16ohm
• Frequency Response:
  • 5Hz~60kHz +0dB/-3dB]
  • 20Hz~20kHz +0dB/-0.3dB
• Total Harmonic distortion: 0.005% (125W, 8ohm, 20-20kHz) (CCIF IMD, DFD IMD)
• Damping Factor: 500 (8ohm, 20Hz-20kHz)
• Input Sensitivity:
  • Phono input
    • MM: 3.6 mV / 36 kohm
    • MC (Low): 400 μV / 33 ohm
    • MC (Mid): 400 μV / 100 ohm
    • MC (High): 400 μV / 390 ohm
• RIAA Deviation20 Hz – 20 kHz ±0.5 dB (MM/MC)
• Phono Maximum Input: MM : 80mV / MC : 8mV
• Input Sensitivity: CD/LINE/RECORDER350 mV/41kohm (Unbalanced) / 700 mV/36kohm
• Input Sensitivity: Power Amp input
  • Unbalanced: 1.58V / 41kohm (Gain : 29dB)
  • Balanced: 3.16V / 15kohm (Gain : 24dB)
• SN Ratio:
  • PHONO (MM): 88dB
  • PHONO (MC): 76dB
  • CD: 122dB
  • Balanced: 122dB
• Headphone Output Level: 130mW / 32 ohms
• Tone Control
  • BASS : 50Hz ±10dB
  • TREBLE : 15kHz ±10dB
• Power Consumption: 270W 0.1W (at Standby)

Audio/ Video

• Phono Input:
  • Yes (MM / MC)
  • Marantz Musical Premium Phono EQ w/ Selectable MC impedance (3 position)
  • PHONO (MC Low): 400 μV / 33Ω
  • PHONO (MC Mid): 400 μV / 100Ω
  • PHONO (MC High): 400 μV / 390Ω
  • PHONO (MM): 3.6 mV / 39kΩ
• Analog Input (include Phono) / REC Out (RCA):
  • 4 /1
  • (LINE1, LINE2, PHONO: Thick nickel-plated independent terminals)
  • (RECORDER: Thick nickel-plated independent terminals)
• Balanced XLR input: 2
• Power Amp Direct: Yes [RCA (Thick nickel-plated independent terminals) / XLR]
• Pre out: Yes [RCA (Thick nickel-plated independent terminals) / XLR]
• 2 sets of Speaker Output: Yes (Bi-wiring)
• Speaker Terminal: Marantz Original SPKT-100+ 2 (High quality and high-purity copper plated)
• Headphone Output: 1(Turns off the speaker automatically when headphone is inserted)

Control/ Other

• Remote Control Bus Terminal: Yes (RC-5 In / Out)
• Remote Internal / External Switch: Yes
• Flasher Input: Yes
• AC Inlet: Yes
• Other: F.C.B.S.(Floating Control Bus System)
• Remote Controller: 10 series Universal Remote control
• Unit control (Button)Tact Switch : 1 POWER
• Unit control (Knob): 2 VOLUME, INPUT SELECTOR
• LEDPOWER:
  • 1 White
  • Protection: 1 Orange
  • Illumination (Edge): White
  • Interior: White
• Front Panel Display: New HD TFT Color Display
• Dimmer for Front Display: 20 steps
• Level meter: Yes (HD Display)
• Volume Display
  • -infinity/-99.5dB – 0dB / 0.5 step (default)
  • 0-100 / 0.5 step
  • switchable
• Last Function Memory: Yes
• Auto Standby Mode: Yes
• Remote Controller: RC004PMND
• Battery: Yes (AAA ×2)
• Power Cord: Yes (ALL region / Audio Grade / OFC)
• Other: CoA card
